Toro 03731 - Installing the Turf-Compensation; Spring; Adjusting the Verticutter; Mounting the Verticutter Reel

4
Installingthe
Turf-CompensationSpring
Partsneededforthisprocedure:
1
Turf-compensationassembly
1Longbolt
2
Carriagebolt
3Flangelocknut
1Flangenut
Procedure
Installtheturfcompensationspringassemblyonthe
samesideasthereelmotor(Figure4andFigure7).
g196548
Figure7
1.Longbolt4.Flangelocknuts
2.Compensationspring
assembly
5.Flangenut
3.Carriagebolts
5
AdjustingtheVerticutter
NoPartsRequired
Procedure
RefertoAdjustingtheVerticutter(page9).
6
MountingtheVerticutter
Reel
NoPartsRequired
Procedure
Important:Whenloweringtheverticutterreels,
caremustbetakentopreventdamagetothereel
bladesduetocontactwithaconcreteoorora
pavedsurface.Lowerthetransportrollersbefore
loweringtheverticutterstoaconcreteoorora
pavedsurface.
Verticutterreelsaremountedtothetractionunitthe
samewayreelcuttingunitsare.Refertothetraction
unitOperator'sManualformountinginstructions.
Installthereelmotorandgreasethesideplateuntil
excessgreaseoozesoutofthereliefvalve;referto
LubricatingtheVerticutter(page12).
8
