15.
Remove
and
retain
all
engine
output
shaft
hardware
(
Figure
7
).
Note:
Y
ou
may
discard
the
set
screws.
g274554
Figure
7
1.
Gearbox
4.
W
asher
7.
Gearbox
gasket
2.
Bolt
5.
Engine
gear
8.
Set
screw
3.
Lock
washer
6.
Engine
adapter
9.
Engine
16.
Clean
the
frame
and
check
for
damage
or
wear
.
17.
Check
the
gearbox
gasket
for
damage
or
wear;
replace
the
gasket
if
it
is
damaged.
6
5
7
