Installation

Note:Ifthemachineisequippedwithan

incandescentlightkit,youmayneedtoorderanew

kit;contactyourauthorizedT orodistributorformore

information.

InstallingaGearboxVent

NoPartsRequired

Procedure

Ifyourmachinedoesnothavethetallventillustrated

inFigure1,obtaintheGearboxVentKitforyour

modelfromyourauthorizedT orodistributorandinstall

theventbeforereplacingtheengine.

g027876

Figure1

1.Vent

RemovingtheExisting

Engine

NoPartsRequired

Procedure

Important:Retainallremovedpartsforreuse

unlessotherwisenoted.

1.Drainthegearbox;refertoyourOperator’s

Manual.

2.Removeanddiscardthenutsattachingthe

enginetothegearbox(Figure8).

3.Supportthegearboxfrombelowsothatitdoes

notfallwhenyouremovetheengine.

4.Removeanddiscardthewireharness.

5.Removetheinterlockmoduleandfasteners

(Figure2).

g262137

Figure2

1.Interlockmodule

6.Removethebrakeandtractionlevergrips

(Figure3).
