FOREWORD
This operator's manual has instructions on safety, proper set-up and operation, adjustments and maintenance.
Therefore, anyone involved with the product, including the operator, should read and understand this manual. This
manual emphasizes safety, mechanical and general product information. DANGER, WARNING and CAUTION
identify safety messages. Whenever the triangular safety alert symbol appears, understand the safety message that
follows. For complete safety instructions, read pages 3–5. IMPORTANT highlights special mechanical information
and NOTE emphasizes general product information worthy of special attention.
Whenever you have questions or need service, contact your local authorized Toro Distributor. In addition to having
a complete line of accessories and professional turf care service technicians, the distributor has a complete line of
genuine TORO replacement parts to keep your machine operating properly. Keep your TORO all TORO. Buy
genuine TORO parts and accessories.
SAFETY INSTRUCTIONS 3–5
SYMBOL GLOSSARY 6–8
SPECIFICATIONS 9–10
BEFORE OPERATING 11
Check The engine Oil 11
Fill The fuel Tank 11
Check Cooling System 11
Check Hydraulic System Fluid 12
Inspect The fuel Filter 13
Check Tire Pressure 14
Check Reel to Bedknife Contact 14
Check Torque of Wheel Nuts 14
CONTROLS 15–16
OPERATING INSTRUCTIONS 17
Break-In Period 17
Starting Instructions 17
Bleeding The fuel System 17
Check Interlock System Operation 18
Preparing The machine For Mowing 19
Training Period 19
Before Mowing 19
Mowing Procedures 19
Transport Operation 20
Inspection and Clean-up After Mowing 20
Towing The traction Unit 21
MAINTENANCE 22
SERVICE INTERVAL CHART 22
DAILY MAINTENANCE CHECKLIST 22
MAINTENANCE SCHEDULE 23
LUBRICATION 24
General Air Cleaner Maintenance 25
Servicing Air Cleaner 25
Cleaning Radiator and Screen 25
Changing The Engine Oil and Filter 26
Replacing The Fuel Filter 26
Changing Hydraulic Oil and Filter 27
Checking Hydraulic Lines and Hoses 27
Adjusting Cutting Unit Lift/Drop 27
Adjust Valve Clearance 28
Torque Cylinder Head Bolts 28
Battery Care 28
Battery Storage 29
Fuses 29
IDENTIFICATION AND ORDERING 29
WARRANTY 30
