7
InstallingtheOilCooler
Optional
NoPartsRequired
Procedure
Ifyouareoperatingthemachineinanareawhere
ambienttemperaturesrangefrom20to49°C(70to
120°F),orifyouusethemachineforheavy-dutyuse
(mowingotherareasthangreens,suchasfairwaysor
verticutting),installtheHydraulicOilCoolerKit(Part
No.104-7701)tothemachine.
8
InstallingtheCuttingUnits
Partsneededforthisprocedure:
3
Offsetlifthook(RefertotheCuttingUnitOperator’s
Manualfortheinstallationinstructions)
6
Screw(suppliedwiththecuttingunit)
1
Bolt(#10x5/8inch)
1
Jamnut(#10)
3
Cuttingunit(soldseparately)
6
Ballstud(suppliedwiththecuttingunit)
3
Grassbasket
Procedure
Note:Whensharpening,settingtheheightofcut,
orperformingothermaintenanceproceduresonthe
cuttingunits,storethecutting-unitreelmotorsinthe
supporttubestopreventdamagetothehoses.
Important:Donotraisethesuspensiontothe
transportpositionwhenthereelmotorsarein
theholdersinthemachineframe.Damagetothe
motorsorhosescouldresult.
1.Removethecuttingunitsfromthecartons.
Assembleandadjustthemasinstructedinthe
cuttingunitOperator'sManual.
2.Slidethecuttingunitunderthepullframewhile
hookingthelifthoopontotheliftarm.
3.Slidethesleevebackoneachballjointreceiver
andhookthereceiverontothecuttingunitball
stud(Figure10).
g021274
Figure10
1.Pulllinkextension3.Balljointreceiver
2.Pullarm
4.Mountthebasketontothecarrierframe.
5.Adjustthepulllinksuntilthereis2to3mm
(1/16to1/8inch)clearancebetweenthelipof
thebasketandthereelblades.Ensurethatthe
basketlipsareequidistantfromthereelblades
allthewayacrossthereelblades.
6.Alignthesocketsintheballjointssotheopen
sideofthesocketiscenteredtowardtheball
stud.Tightenthejamnutstosecurethesockets
inposition.
7.Ensurethatthereisapproximately13mm
(1/2inch)ofthethreadsexposedoneach
reel-drive-motormountingbolt(Figure11).
14
