Figure 4
1. Brake fluid reservoir
2. Full line
CHECK WHEEL NUT TORQUE
CHECK TIRE PRESSURE
Check tire pressure every 8 hours or daily.
Maximum air pressure in the front tires is 1,4 kg/cm
2
and 2,3 kg/cm
2
in the rear (23”) tires tires. Optional
rear (24”) tire pressure is 18 psi maximum.
1. The air pressure needed is determined by the
payload carried.
2. The lower the air pressure, the less the com-
paction and tire marks are minimized. Lower
pressure should not be used for heavy payloads
at high speeds. Tire damage may result.
3. Higher pressures should be used for heavier pay-
loads at higher speeds.
Do not exceed the maximum pressure. Use the fol-
lowing charts to determine correct tire pressures for
tire size and payload of vehicle.
13
Before Operating
➀
➁
Failure to maintain proper torque could result in
failure or loss of wheel and may result in personal
injury. Torque front and rear wheel nuts to 61–88
Nm after 1–4 hours of operation and again after 10
hours of operation and every 200 hours thereafter.
WARNING
373
411
448
485
523
560
597
373
411
448
485
523
560
635
672
709
784
821
858
896
933
970
635
672
709
784
821
858
896
933
970
635
6955 9783 110 124138152
69
55
9783 110 124 138
165179193207 221
69
55
97
83
110 124
138 152
Tire pressure (Nm)
20” FRONT TIRES
Maximum Total Front Axle Weight (kg)
Maximum Total Rear Axle Weight (kg)
Maximum Total Rear Axle Weight (kg)
24” EXTRA WIDE REAR TIRES
23” REAR TIRES (Standard)
TIRE PRESSURE (Nm)
TIRE PRESSURE (Nm)
