5. Always install or remove bed support from out-
side of bed.
6. Do not try to lower bed with bed safety support
on cylinder.
Figure 16
1. Bed support 2. Storage stud
Figure 17
1. Bed support 3. Bed
2. Cylinder barrel
JACKING THE VEHICLE
1. Do not start the engine while the vehicle is on
jack, because engine vibration or wheel move-
ment could cause the vehicle to slip off jack.
2. Do not work under the vehicle without jack
stands supporting it. The vehicle could slip off
jack, injuring any one beneath it.
3. The jacking point at the front of the vehicle is
under the front center frame support and at the
rear it is under the axle tube.
4. When jacking up front of the vehicle, always
place a 50 x 100mm block (or similar material)
between the jack and vehicle frame.
Figure 18
1. Front jacking point
Figure 19
1. Rear jacking points
Locations For Selected
Maintenance Procedures
Figure 20
1. Air cleaner cover
30
Maintenance
➀
➀
➀
