Controls
16
while the engine is running. If the light flickers or
remains ON, stop the vehicle, turn off the engine and
check the oil level. If the oil level was low, but
adding oil does not cause light to go out when the
engine is restarted, turn the engine off immediately
and contact your local TORO distributor for assis-
tance.
Ignition Switch (Fig. 7)—The ignition switch, used
to start and stop the engine, has three positions: OFF,
RUN and START. Turn the key clockwise—START
position—to engage the starter motor. Release the
key when the engine starts. The key will move auto-
matically to the ON position. To shut the engine off,
turn the key counterclockwise to OFF.
To check warning light operation:
1. Apply the parking brake.
2. Turn the ignition key to “ON”, but do not start
the engine. The oil pressure light should glow.
If the light does not function, either a bulb is
burned out or there is a malfunction in the sys-
tem which must be repaired.
Hour Meter (Fig. 8)—Indicates the total hours of
machine operation. The hour meter starts to function
whenever the key switch is turned to the “ON” posi-
tion.
Light Switch (Fig. 8)—Toggle this switch to acti-
vate the headlights. Push to turn lights “ON”.
Fuel Gauge (Fig. 8)—Shows the amount of fuel in
the tank. Operates only when the ignition switch is
in the “ON” position.
3rd High Lockout Switch (Fig. 8)—Moving this
switch to the slow position and removing the key
will prevent use of third gear when in the High
range. The engine will shut off if the shift lever is
moved to third gear when in the High range. Install
the key with its teeth pointing downward. Push the
key in to turn it. The key is removable in either posi-
tion.
Figure 8
1. Light switch
2. Hour meter
3. Fuel gauge
4. 3rd High lockout switch
5. Steering wheel
Steering Wheel (Fig. 8)—Turns the vehicle. If the
engine stalls or the power assist fails, vehicle steer-
ing will require greater effort.
Tachometer (optional-not shown)—Indicates engine
RPM. Gear selection graphics indicate speed.
Remote Hydraulic Lever (optional-not shown)—
Controls hydraulic flow to optional quick rear cou-
plers.
