28
Maintenance
GREASING BEARINGS AND
BUSHINGS
The vehicle has (33) grease fittings that must be
lubricated regularly with No. 2 General Purpose
Lithium Base Grease. If the machine is operated
under normal conditions, lubricate all bearings and
bushings after every 100 hours of operation. More
frequent lubrication is required if used for heavy
duty vehicle operations.
The grease fitting locations and quantities are: Tie
rod ends (4) (Fig. 11), Front ball joints (4) (Fig. 11),
Rear drive shafts (6) (Fig. 12), Steering shaft (1)
(Fig. 13), Front pivot bushings (2) (Fig. 14) and
Pedal pivots (4) (Fig. 15).
IMPORTANT: When greasing drive shaft univer-
sal shaft bearing crosses, pump grease until it
comes out of all 4 cups at each cross.
1. Wipe the grease fitting clean so foreign matter
cannot be forced into the bearing or bushing.
2. Pump grease into the bearing or bushing.
3. Wipe off excess grease.
Figure 11
Figure 12
Figure 13
Figure 14
Figure 15
