Symbols Glossary
THROWN OR FLYING OBJECTS,
FACE EXPOSURE
SEVERING OF FINGERS OR
HAND, ENGINE FAN
RIDING ON THIS MACHINE IS
ALLOWED ONLY ON A PASS-
ENGER SEAT & ONLY IF THE
DRIVER'S VIEW IS NOT HINDERED
SHUT OFF ENGINE & REMOVE
KEY BEFORE PERFORMING
MAINTENANCE OR REPAIR WORK
MACHINE TIPPING USE CAUTION ON STEEP HILLS MACHINE TIPPING MACHINE TIPPING
DO NOT JUMP FROM TIPPING
MACHINE
HOLD TIGHTL & BRACE FEET LEAN AWAY FROM TIP HOLD HIP RESTRAINT & HAND
HOLD, BRACE FEET
STAY CLEAR OF ARTICULATION
AREA WHILE ENGINE IS RUNNING
RUNOVER/BACKOVER, VEHICLE REAR POWER TAKE OFF
(9)
GREASE LUBRICATION POINT GREASE LUBRICATION POINT
2.
4.
3.
1.
< 680 kg
< 90 kg
< 1179 kg
635 kg
< 1814 kg
635 kg
MACHINE DIRECTION OF MOVEMENT BEFORE LEAVING OPERATOR POSITION, TURN OFF IGNITION, LOCK PARKING BRAKE,
DISENGAGE PTO, REMOVE KEY FROM IGNITION.
BEFORE LEAVING OPERATOR POSITION,
TURN OFF IGNITION AND REMOVE KEY.
LOAD RATING, HOPPER LOAD RATING, TRAILER AND HITCH
LOAD RATING
< 1179 kg
726 kg
< 1905 kg
LOAD RATING
< 318 kg
LOAD RATING, HOPPER
