Lubrication
Themachinehasgreasettingsthatmustbe
lubricatedregularlywithNo.2lithiumgreaseafter
every100hoursofoperation.
Lubricatethefollowingbearingsandbushings:
•Frontwheelbearing(1)(Figure19)
g002714
Figure19
•Traction-pedalpivot(1)(Figure20)
g002715
Figure20
•Rearhitch(5)(Figure21)
g002716
Figure21
•Steeringcylinderrodend(1)—Model08705only
(Figure22)
g002717
Figure22
•Steeringpivot(Figure23)
Note:Theushttingonthesteeringpivot(Figure
23)requiresagreasegunnozzleadapter.Order
ToroPartNo.107-1998fromyourauthorizedT oro
distributor.
g007452
Figure23
GreasingtheMachine
ServiceInterval:Every100hours
1.Wipethegreasettingcleansothatforeign
mattercannotbeforcedintothebearingor
bushing.
2.Pumpgreaseintothebearingorbushing.
3.Wipeupexcessgrease.
