Toro 08703 - Replacing the Hydraulic Filter

g002704
Figure42
1.Hydraulic-reservoircap
4.Removethecapfromthereservoir.
5.Removethedipstickfromthellerneckand
wipeitwithacleanrag.
6.Insertthedipstickintothellerneck;then
removeitandchecktheleveloftheuid(Figure
43).
Whenthereservoirisproperlylledwith
hydraulicuid,youshouldseetheuid
levelbetweentheupperandlowermarks
(necked-downarea)onthedipstick.
Important:Iftheuidlevelisbetweenthe
upperandlowermarks,nouidadditionis
required.
g035109
Figure43
1.Upperlimit2.Lowerlimit
7.Iftheuidlevelistoolow,slowlyaddthe
speciedhydraulicuidtothereservoiruntilthe
uidlevelreachesthenecked-downareaonthe
dipstick.
Important:Topreventsystem
contamination,cleanthesurfaceof
theofhydraulic-uidcontainersbefore
openingthem.Ensurethatthepourspout
andthefunnelareclean.
Important:Donotoverllthereservoirwith
hydraulicuid.
8.Installthereservoircap.
ReplacingtheHydraulic
Filter
ServiceInterval:Every1,000hours—Ifyou
areusingtherecommended
hydraulicuid,replacethe
hydrauliclter.
Every800hours—Ifyouarenotusingthe
recommendedhydraulicuidorhaveever
lledthereservoirwithanalternativeuid,
replacethehydrauliclter.
1.Parkthemachineonalevelsurface,shutoffthe
engine,engagetheparkingbrake,andremove
thekey.
