•Tightenthecapscrewtoincreasethespeed.
•Loosenthecapscrewtodecreasethespeed.
3.Tightenthejamnutstosecurethesocket-head
capscrews.
4.Repeatsteps1through3asnecessary.
AdjustingtheFull-speedTracking
Ifyouneedtoadjustthefull-speedtracking,referto
themachineOperator’sManual.
8
InstallingtheStopPlates
NoPartsRequired
Procedure
Installthestopplatesintheexactpreviouslocations,
andsecurethemwiththeexistingbolts(Figure7).
Operation
UsingtheSpeedLimiterKit
Ifyoulowertheattachmentwhiledrivingoveracertain
speed,thecamdoesnotlimitthedrivingspeeduntil
youmanuallydecreasethespeedbymovingthe
controlhandlesaccordingly.
Ifyouraisetheattachmentwhiledrivingatthefull
cam-limitedspeed,themachinemightnotmoveatthe
regularfullspeeduntilyoutakesomepressureoffthe
controlhandles.T odoso,simplybackthehandles
slightlyawayfromthefull-forwardposition.
DisablingtheSpeedLimiter
Kit
1.Usingatwistingmotion,pullthespringsoffthe
bolts(Figure18).
g024707
Figure18
1.Slot2.Spring
2.Latchthehookontheendofeachspringinto
theslotintheappropriateliftbracket.
Whenyouwanttousethespeedlimiterkitagain,
installthespringsontheboltsinthereversemanner
inwhichyouremovedthem.
