Figure4
1.Chain4.Washer(3/8x7/8inch)
2.Spacer5.Locknut(3/8inch)
3.Bolt(3/8x2-1/2inches)
3.Threadashacklethroughthebottomlinkofeachchain
ontheliftarm(Figure5).
Figure5
1.Chain3.Clevispin(3/8x1-1/2
inches)
2.Shackle4.Cotterpin
4.Secureeachshackletothedrag-mat-carrierassembly
asillustratedinFigure5usingaclevispin(3/8x1-1/2
inches)andacotterpin.
Note:Forproperoperationoftheattachment,the
chainsmustbeslackwhenthedragmatisinthe
lowered(operating)position.
2
InstallingaMat
Partsneededforthisprocedure:
1
Steelmat(notincludedinthiskit,orderseparately)
1
Coconut-bermat(notincludedinthiskit,order
separately)
11Matretainer
11
Bolt(3/8x1inch)
11
Flangenut(3/8inch)
Procedure
1.Lineup1edgeofthematwiththerearedgeofthe
carrier.
Important:Ifyouareinstallingthesteelmat,
positionthematsothatthetabsalongthe
outsideedgefacerearwardwhentheinstallation
iscomplete.Thisorientationpreventsthetabs
frombendingandothersubsequentdamagefrom
occurring.
Figure6
1.Tabsfacingrearward
5
