Donotusethemaximumspeedwhenusinga
mountedortowedattachment.
Important:Donotoperatethemachineinreverse
withtheattachmentinthedown(operating)
position,ortheattachmentcouldbeseverely
damaged.
IgnitionSwitch
Theignitionswitch(Figure11),usedtostartandshut
offtheengine,has3positions:OFF,RUN,andSTART.
RotatethekeyclockwisetotheSTARTpositionto
engagethestartermotor.Releasethekeywhenthe
enginestarts,andthekeymovestotheONposition.
Toshuttheengineoff,rotatethekeycounterclockwise
totheOFFposition.
g002710
Figure11
1.Ignitionkey
3.Chokecontrol
2.Throttlecontrol
ChokeControl
Tostartacoldengine,closethecarburetorchoke
bymovingthechokecontrol(Figure11)uptothe
CLOSEDposition.Aftertheenginestarts,regulatethe
choketokeeptheenginerunningsmoothly.Assoon
aspossible,openthechokebymovingitdownto
theOPENposition.Awarmenginerequireslittleor
nochoking.
ThrottleControl
Thethrottlecontrollever(Figure11)connectstoand
operatesthethrottlelinkagetothecarburetor.The
controlhas2positions:SLOWandFAST.Theengine
speedcanbevariedbetweenthe2settings.
Note:Youcannotshutofftheenginebyusingthe
throttlecontrol.
LiftLever
Toraisetheattachment,pulltheliftlever(Figure12)
back;tolowertheattachment,pushtheleverforward.
FortheFLOATposition,movetheleverintothedetent
position.Whenyouattainthedesiredposition,release
theleveranditwillreturntoneutral.
g002711
Figure12
1.Liftlever4.Frontliftcontrol(optional)
2.Parkingbrake5.Rearremotehydraulics
control(optional)
3.Hourmeter
Note:Themachinehasadouble-actingliftcylinder.
Youcanapplydownpressuretotheattachmentfor
certainoperatingconditions.
ParkingBrake
Toengagetheparkingbrake(Figure12),pullback
ontheparking-brakelever.Todisengageit,pushthe
leverforward.
Note:Youmayhavetorotatethetractionpedal
slowlyforwardandbackwardtodisengagetheparking
brake.
HourMeter
Thehourmeter(Figure12)indicatesthetotalhoursof
machineoperation.Thehourmeterstartstofunction
wheneveryourotatethekeyswitchtotheONposition.
13
