Toro 136–5850 - Removing the Rear Wheel

RemovingtheRearWheel
1.Loosenandremovethenutfromtheaxlebolt;setthe
nutaside(Figure2).
g187971
Figure2
1.Nut3.Axlebolt
2.Wheel
2.Removethewheelassemblyandwheelcover(Figure3).
g187970
Figure3
1.Wheelassembly2.Wheelcover
3.Removetheboltfromtheretaineranddiscardit
(Figure4).
g187972
Figure4
1.Bolt(5/16x3/4inch)3.Height-of-cutlever
2.Retainer
2
