Toro LX420 13AX60RG744 User Manual (English)

Questions and Answers:

M
Matthew Davis PhDAug 13, 2025
Why Toro LX420 13AX60RG744 Lawn Mower engine fails to start?
- D
  Damon PearsonAug 13, 2025
  There are several reasons why your Toro Lawn Mower engine might fail to start: * The PTO (Blade Engage) lever may be engaged, so place it in the OFF position. * The parking brake might not be engaged; make sure to engage it. * The spark plug wire could be disconnected; connect it to the spark plug. * The throttle/choke control may not be in the correct starting position; move it to the CHOKE position. * The fuel tank may be empty or the fuel stale; fill it with clean, fresh gas (less than 30 days old). * A blocked fuel line could be the issue; clean the fuel line or replace the fuel filter. * The spark plug could be faulty; clean, adjust the gap, or replace the plug. * The engine might be flooded; crank the engine with the throttle in the FAST position.
C
Charles DanielAug 16, 2025
What to do if my Toro LX420 13AX60RG744 will not mulch grass?
- P
  Patrick KramerAug 16, 2025
  If your Toro Lawn Mower isn't mulching grass effectively: * Ensure the engine speed isn't too low by placing the throttle in the FAST position. * Avoid mowing wet grass; wait until it's dry. * If the grass is excessively high, mow once at a high cutting height, then again at the desired height, or make a narrower cutting swath. * Check for a dull blade and sharpen or replace it.
M
martinezjessicaAug 20, 2025
What to do if Toro LX420 13AX60RG744 engine runs erratic?
- B
  bdavisAug 20, 2025
  If your Toro Lawn Mower engine is running erratically, consider the following: * Ensure the unit is not running with the CHOKE activated; move the Throttle/Choke Control out of the CHOKE position. * Check for loose spark plug wires and connect/tighten them. * Look for a blocked fuel line or stale fuel; clean the fuel line and fill the tank with fresh gasoline (less than 30 days old). * The vent in the gas cap may be plugged; clear the vent or replace the cap if damaged. * There might be water or dirt in the fuel system; drain the fuel tank. * A dirty air cleaner could be the problem; replace the air cleaner paper element or clean the foam precleaner.
C
chelsey80Aug 25, 2025
Why Toro LX420 13AX60RG744 idles poorly?
- E
  Ellen MolinaAug 25, 2025
  A Toro Lawn Mower may idle poorly because: * The spark plug is fouled, faulty, or has a gap that is too wide; replace the spark plug. * The air cleaner is dirty; replace the air cleaner element or clean the pre-cleaner.
A
Antonio GomezAug 28, 2025
Why Toro LX420 13AX60RG744 has uneven cut?
- A
  alvaradoashleeAug 28, 2025
  An uneven cut with your Toro Lawn Mower may result from: * A deck that is not balanced properly; perform a side-to-side deck adjustment. * A dull blade; sharpen or replace the blade. * Uneven tire pressure; check the tire pressure in all four tires.
S
Sabrina WatersSep 1, 2025
Why does my Toro Lawn Mower engine overheat?
- S
  Sarah GordonSep 1, 2025
  Your Toro Lawn Mower engine may overheat due to: * Low engine oil level. Fill the crankcase with the proper capacity and weight of oil. * Restricted airflow. Clean grass clippings and debris from around the engine’s cooling fins and blower housing.
J
joseph73Sep 4, 2025
Why Toro LX420 13AX60RG744 Lawn Mower has excessive vibration?
- K
  Kristin MorrisSep 4, 2025
  Excessive vibration in your Toro Lawn Mower can be caused by: * A loose or unbalanced cutting blade. Tighten the blade and spindle. * A damaged or bent cutting blade. Balance or replace the blade.
G
Gerald BrooksSep 8, 2025
Why Toro LX420 13AX60RG744 Lawn Mower engine hesitates at high RPM?
- U
  uhowellSep 8, 2025
  If your Toro Lawn Mower engine hesitates at high RPM, it might be because the spark plug gap is too close. Remove the spark plug and reset the gap.

Toro LX420 13AX60RG744 Specifications

General

Engine Manufacturer	Kohler
Engine Model	Courage
Horsepower	20 HP
Cutting Width	42 inches
Transmission Type	Hydrostatic
Fuel Capacity	3 gallons
Deck Material	Steel
Speed	5.5 mph
Warranty	3 year limited
Cutting Height	1.5-4 inches

Summary

FINDING MODEL NUMBER

CUSTOMER SUPPORT

SECTION 1: IMPORTANT SAFE OPERATION PRACTICES

GENERAL OPERATION

Foundational instructions for safe and proper operation of the lawn tractor.

SLOPE OPERATION

Critical safety procedures and precautions for operating the tractor on inclines and slopes.

CHILDREN

Safety guidelines specifically addressing the risks and precautions related to children around the tractor.

TOWING

Instructions and warnings for safely towing equipment with the lawn tractor.

SERVICE

General safety advice and procedures related to servicing the lawn tractor.

GENERAL SERVICE

SAFETY SYMBOLS

SECTION 2: SAFETY AND INSTRUCTIONAL LABELS

OPERATING MODES

Details on different operational modes, including normal mowing and reverse caution mode.

SECTION 3: SLOPE GAUGE

SECTION 4: TRACTOR SET-UP

Attaching The Steering Wheel

Procedure for securely attaching the steering wheel to the tractor's steering shaft.

Attaching the Battery Cables

Instructions for correctly connecting the tractor's battery cables for power.

Tire Pressure

Recommended tire pressure settings and warnings for safe operation.

Attaching The Seat

Guide for properly installing and adjusting the tractor seat for operator comfort.

Shipping Brace Removal

Steps to safely remove the shipping brace before operating the tractor.

Setting the Gauge Wheels

Instructions for adjusting deck gauge wheels to ensure proper cutting height.

Gas and Oil Fill-up

Procedures for safely filling the fuel tank and checking engine oil before operation.

SECTION 5: KNOW YOUR LAWN TRACTOR

SECTION 6: OPERATING YOUR LAWN TRACTOR

Safety Interlock System

Explanation of the safety interlock system and its function to prevent unintended operation.

Reverse Caution Mode

Details on how to engage reverse mode with the blades engaged, including safety precautions.

Starting the Engine

Step-by-step instructions for safely starting the tractor's engine.

Stopping the Engine

Procedures for properly shutting down and securing the tractor's engine.

Driving The Tractor

Guidance on basic forward and reverse operation, speed control, and stopping.

Driving On Slopes

Crucial safety advice and techniques for operating the tractor on inclines safely.

Setting The Cruise Control

Instructions on how to engage and use the cruise control feature for maintaining speed.

Using the Deck Lift Lever

How to operate the deck lift lever to adjust cutting height and maneuver the deck.

Engaging the Parking Brake

Steps to correctly engage and disengage the tractor's parking brake.

Engaging the Blades

Procedure for safely engaging the PTO and cutting blades for mowing.

Mowing

Best practices and tips for effective and safe lawn mowing with the tractor.

SECTION 7: MAKING ADJUSTMENTS

Seat Adjustment

How to adjust the tractor seat forward or backward for operator comfort.

Leveling the Deck

Instructions for adjusting the cutting deck for a level and uniform cut.

Side to Side

Procedure to adjust the deck side-to-side for an even cut across the lawn.

Parking Brake Adjustment

Steps to adjust the parking brake if it is not holding effectively.

Steering Adjustment

How to adjust steering linkages to correct pulling or alignment issues.

SECTION 8: MAINTAINING YOUR LAWN TRACTOR

Engine

Overview of engine maintenance requirements and procedures.

Checking the Oil Level

Critical steps to check and maintain the correct engine oil level before each use.

Adding Oil

Instructions on how to add the correct type and amount of oil to the engine.

Changing the Engine Oil

Procedure for draining and replacing the engine oil and filter at recommended intervals.

Changing the Oil Filter

Steps for safely removing and installing a new engine oil filter.

Re-filling the Crankcase with Oil

Guidance on adding oil after a change and verifying the level.

Air Filter

Information on servicing and replacing the engine's air filter element for optimal performance.

Spark Plug

Instructions for checking, gapping, and replacing the spark plug for engine ignition.

Fuel Filter

Guidance on inspecting and replacing the inline fuel filter for proper fuel delivery.

Cleaning the Engine

Procedures for cleaning the engine exterior and cooling fins to prevent overheating.

Lubrication

Details on lubricating key points such as axles, rims, and pivot linkages.

SECTION 9: SERVICE

Tires

Information on recommended tire pressure and service.

Fuse

Location and replacement instructions for the tractor's electrical system fuse.

Cutting Blades

Steps for removing, sharpening, and replacing the mower deck blades.

Battery

Information on the sealed battery, its terminals, and proper handling.

Jump Starting

Safe procedures for jump-starting the tractor's battery using another vehicle.

Charging

Instructions for charging the tractor's battery using an external charger.

Cutting Deck Removal

Step-by-step guide for safely removing the mower deck from the tractor.

Changing the Deck Belt

Procedure for replacing the mower deck drive belt.

Changing The Transmission Drive Belt

Information on replacing the tractor's transmission drive belt.

Changing the Lower Deck Belt (Model LX460 only)

Specific instructions for changing the lower deck belt on the LX460 model.

SECTION 10: OFF-SEASON STORAGE

Engine

Specific procedures for preparing the engine for off-season storage.

SECTION 11: MAINTENANCE CHART

SECTION 12: TROUBLESHOOTING

SECTION 13: SPECIFICATIONS*

ELECTRIC SCHEMATIC

CALIFORNIA EMISSION CONTROL WARRANTY STATEMENT

MANUFACTURER'S WARRANTY COVERAGE:

Overview of the duration and scope of the manufacturer's warranty for the tractor.

OWNER'S RESPONSIBILITIES:

Owner's duties regarding maintenance and care to ensure warranty validity.

GENERAL EMISSIONS WARRANTY COVERAGE:

Explanation of warranty terms for emission-related parts and their coverage period.

HOW TO OBTAIN SERVICE:

Instructions on how to get warranty service and find an authorized dealer.

HOW LOCAL LAWS RELATE TO THIS WARRANTY:

Information on how local laws may affect warranty rights and limitations.
