DischargingtheClippings
Side-dischargeorrear-dischargetheclippingswhencuttingverytallgrass.
WARNING
Thebladeissharp;contactingthebladecanresultinseriouspersonalinjury.
Shutofftheengineandwaitforallmovingpartstostopbeforeleavingtheoperatingposition.
Side-DischargingtheClippings
Ifthebagisonthemachine,removeitandinserttherearplug;refertoRemovingtheGrassBag(page18).
Important:Ensurethattherearplugislockedinplace.Tolocktheplug,raisethereardeector
(Figure19),rmlypushthepluginuntilitsnapsintoplacebehindthetabs,androtatetheleveronthe
plugtotheleft(Figure19).
g231918
Figure19
Note:T ounlocktheplug,rotatetheleverontheplugtotheright.
InstallingtheSide-DischargeChute
1.Unlocktheside-dischargedeector(AofFigure20).
2.Liftopentheside-dischargedeector(BofFigure20).
3.Installtheside-dischargechuteandclosethedeectorontothechute(B,C,andDofFigure20).
