Toro 22197 - Product Overview; Controls; Operation; Checking the Engine Oil Level

ProductOverview
Figure8
1.Handle
6.Airlter
2.Throttlecontrollever
7.Cuttingheightlever
3.Grassbag8.Sparkplug
4.Fueltank
9.Oilll/dipstick
5.Oillter
10.Bladecontrolbar
Controls
Figure9
1.Bladecontrolbar3.Recoilstarterhandle
2.Throttlecontrollever
Operation
Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
Eachtimebeforeyoumow,makesurethatthe
self-propeldriveandthebladecontrolbaroperate
properly.Whenyoureleasethebladecontrolbar,the
bladeandself-propeldriveshouldstop.Iftheydonot,
contactanAuthorizedServiceDealer.
CAUTION
Thismachineproducessoundlevelsinexcessof
85dBAattheoperator’searandcancausehearing
lossthroughextendedperiodsofexposure.
Wearhearingprotectionwhenoperatingthis
machine.
Figure10
1.Warning—wearhearingprotection.
CheckingtheEngineOilLevel
ServiceInterval:Beforeeachuseordaily
Theoilcapacityoftheenginecrankcase(withoil
lter)is29ounces(0.85liters).Useonlyhigh-quality
SAE30orSAE10W30weightdetergentoilthat
hastheAmericanPetroleumInstitute(API)service
classicationSF,SG,SH,orSJ.
Beforeeachuse,ensurethattheoillevelisbetweenthe
AddandFullmarksonthedipstick(Figure11).
