ScrapingMethod
Ifwashingdoesnotremovealldebrisfromunderthe
lawnmower,scrapeitclean.
1.Disconnectthewirefromthesparkplug(Figure12).
2.Drainthefuelfromthefueltank.RefertoEmptying
theFuelTankandCleaningtheFuelFilter.
WARNING
Tippingthelawnmowermaycausethefuel
toleakfromthecarburetororthefueltank.
Gasolineisextremelyammable,highly
explosive,and,undercertainconditions,can
causepersonalinjuryorpropertydamage.
Avoidfuelspillsbyrunningtheenginedryorby
removingthegasolinewithahandpump;never
siphon.
3.Tipthelawnmowerontoitsrightside.
4.Removethedirtandgrassclippingswithahardwood
scraper.Avoidburrsandsharpedges.
5.Turnthelawnmowerupright.
6.Fillthefueltank.
7.Connectthewiretothesparkplug.
CleaningtheDischargeTunnel
andPlug
ServiceInterval:Beforeeachuseordaily
Removetheplugfromthedischargetunnelandclean
itaftereachuse.
Alwaysbesurethatthedischargetunneldoorcloses
securelywhenyoureleasethehandle.Ifthedebris
preventsthedischargedoorfromclosingsecurely,
cleantheinsideofthedischargetunnelandthedoor
thoroughly.
WARNING
Grassclippingsandotherobjectscanbethrown
fromanopendischargetunnelandcauseserious
injuryorkilltheoperatororbystanders.
Neverstartoroperatethelawnmowerunlessone
ofthefollowingistrue:
•Thedischargetunnelplugislockedsecurelyin
thedischargetunnel.
•Thegrassbagislockedinplace.
•Theoptionalsidedischargechuteislockedin
place.
•Thedischargetunneldoorislockedinplace.
CleaningundertheBeltCover
ServiceInterval:Every50hours
Keeptheareaunderthebeltcoverfreeofdebris.
1.Stoptheengineandwaitforallmovingpartstostop.
2.Removetheboltsthatsecurethebeltcover
(Figure34)tothelawnmowerhousing.
Figure34
1.Beltcover
3.Liftoffthecoverandbrushoutallthedebrisaround
thebeltarea.
4.Installthebeltcover.
