Maintenance
30
4. Install the air cleaner cover with the side
indicated as UP facing up and secure the latches
(Fig. 24).
5. Close the rear access cover.
Servicing
the Engine Oil
Change oil after the first 50 operating hours and then
every 75 operating hours thereafter.
Note: Change oil more frequently when
operating conditions are extremely
dusty or sandy.
Oil Type: MIL-L-2104C (API service CD or higher)
Crankcase Capacity: w/filter, 0.84 gal. (3.2 l)
Viscosity: See table below
F
–20 0 20
40 60
80 100
°
C
–30
°
–20 –10
01020
30 40
USE THESE SAE VISCOSITY OILS
32
5W–20, 5W–30
10W–30, 10W–40
Changing the Oil
1. Start the engine and let it run for five minutes.
This warms the oil so it drains better.
2. Park the traction unit so that the drain side is
slightly lower than the opposite side to ensure
that the oil drains completely.
3. Lower the loader arms, chock the wheels, and
stop the engine. Remove the key.
POTENTIAL HAZARD
• Components will be hot if the traction unit
has been running.
WHAT CAN HAPPEN
• Touching hot components can cause burns.
HOW TO AV
OID THE HAZARD
• Allow the traction unit to cool before
performing maintenance or touching any
components.
4. Place a pan under the oil drain tube (Fig. 25).
5. Loosen the clamp and remove the plug (Fig. 25).
6. When the oil has drained completely, replace the
plug and tighten the clamp.
Note: Dispose of the used oil at a certified
recycling center.
1
m-4593
2
3
Figure 25
1. Clamp
2. Oil
drain tube
3. Plug
7. Open the rear access cover; refer to Opening the
Rear Access Cover
, page 27.
8. Remove the oil fill cap and slowly pour
approximately 80% of the specified amount of
oil in through the valve cover.
9. Check the oil level; refer to Checking the Oil
Level, page 14.
10. Slowly add additional oil to bring the level to the
F (full) mark on the dipstick.
