Toro 30353 - Setup; Removing the Existing Mower (if Applicable)

Setup
MediaandAdditionalParts
Description
Qty.
Use
Partscatalog1
Operator'sManual
1
CerticateofCompliance
1
Reviewthematerialandsaveinanappropriateplace:
Note:Determinetheleftandrightsidesofthemachine
fromthenormaloperatingposition.
RemovingtheExistingMower
(ifapplicable)
1.Parkthemachineonalevelsurfacewiththemower
inthefullyraisedposition.Stoptheengine,engage
theparkingbrakeandremovethekeyfromthe
ignitionswitch.
Note:Whenthemowerisintheraisedposition,the
pulllinktorsionspringtension(
Figure2)isreduced
makingitmucheasiertodisconnectthepulllinks
fromthemachine.
g017279
1
2
3
4
5
6
7
Figure2
1.Pulllink(mowerraised)5.Mowerliftchain
2.Shoulderscrew6.Clevispin
3.Retainerpin7.Adjustmentclevis
4.Torsionspring
2.Disconnectthepulllinkfromeachsideofthe
machine(Figure2).
CAUTION
Becarefulwhendisconnectingthepulllinks.
Thepulllinktorsionspringsmaycausesome
rotationofthepulllinksduringtheremoval
process.
A.Removetheshoulderscrewthatsecuresthe
retainerpintothecarrierframe(
Figure2).
B.Carefullyslidetheretainerpinfromthecarrier
frameandthepulllink(Figure2).
3.NotethelocationoftheHOCpinintheHOC
bracketforassemblypurposes(
Figure3).Remove
theHOCpinfromtheHOCbracket.
1
2
G017278
Figure3
1.HOCpin2.HOCbracket
4.Starttheengineandfullylowerthemower.Stopthe
engineandremovethekeyfromtheignitionswitch.
Note:Loweringthemowerontofurnituredollies
willeasetheremovalofthemower.
WARNING
DonotstarttheengineandengagethePTO
switchwhenthePTOdriveshaftisdisconnected
fromthemower.Iftheengineisstartedandthe
PTOshaftisallowedtorotate,seriouspersonal
injuryandmachinedamagecouldresult.If
thePTOdriveshaftisdisconnectedfromthe
mower,removethefuseF1(15amp)fromthe
fuseblocktopreventunintentionalengagement
ofthePTOclutch.
