ProductOverview
Specications
Note:Specicationsanddesignaresubjecttochange
withoutnotice.
Netweight
107kg(235lb)
Attachments/Accessories
AselectionofToroapprovedattachmentsandaccessoriesis
availableforusewiththemachinetoenhanceandexpand
itscapabilities.ContactyourAuthorizedServiceDealeror
Distributororgotowww .Toro.comforalistofallapproved
attachmentsandaccessories.
Operation
AdjustingtheDischarge
Opening
Thedischargeopening(Figure7)isadjustabletoincrease
ordecreaseairoutputvelocityandvolume.Decreasingthe
dischargeopeningsizeincreasesthevelocity.
1.Loosendischargeopeningdeectormountingscrews
(Figure7).
G003812
1
2
Figure7
1.Dischargeopening
deector
2.Mountingscrew
2.Pivotthedeectortothedesiredopening.
3.Tightenthemountingscrews.
SwitchOperation
Lift/Lowerswitch(Figure8)—MoveswitchtotheLift
positiontoraisetheattachmentandtotheLowerpositionto
lowertheattachment.
Float/Power-downSwitch(Figure8)—Movingtheswitch
totheFloatpositionallowstheattachmenttofollowthe
contouroftheground.MovingtheswitchtothePower-down
positionaddsweightfromthemachinetoincreaseground
engagementforce.Highergroundengagementforce
decreasesthetractioncapacityofthemachine.
Important:Onlyrunthedebrisblowerinthe F loat
mode.Neverrunitinthe P o w er -do wn mode,ordamage
totheblowerwilloccur.
