Notice of Confidentiality
This material is property of Tektite Manufacturing
Inc and is not to be used by the recipient for any
purpose other than the purpose for which it was
transmitted. The material remains the property of
Tektite and shall be returned upon request. The
material may not be reproduced or disclosed to third
parties without the written consent of Tektite.
Tolerances:
Unless otherwise
specified
X.X =
1/16"
Angular =
1.0
Drawn By:
Checked By:
Size:
File Name:
Units:
Date:
Date:
Req'd:
Description:
Tektite Manufacturing Inc.
24157 Hwy 3, Box 639, Winkler MB, R6W 4A8, Canada
CNC:
Index Service Part # File Name
Description
Qty
1 A00-0013 TEKT-0009 5MM Bushing 14
2 A00-0014 TEKT-0092 Thick Bushing 6
3 A00-0019 STEP-BOLT1-4X1 Step Bolt, 1/4" x 1", MB 1
4 A00-0020 STEP-BOLT1-4X1-1-4 Step Bolt, 1/4" x 1 1/4", MB 6
5 A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD 7
6 A00-0033 315-080 Rear Wiper Shaft Grommet 1
7 A00-0043 WWF-MOTOR WWF Wiper Motor, 1" Shaft 1
8 A00-0109 302-1160_BLADE Wiper Blade, 16", Narrow Saddle 1
9 A00-0312 TEKT-ASM-049 WWF, Adjustable Radial Arm, 12 1/2" Length 1
10 T02-0004 TOG4000-024 Rear Window Glass 1
11 T02-0009 TOG4000-038 Rear Window Weatherseal 1
Rear Window Assembly
Daryl Furkalo
2014-12-05 Imp.
TOG4000-ASM-009-OP
B
SCALE 0.250
1
2
3
4
5
6
7
8
9
10
11
To Next Page
