Notice of Confidentiality
This material is property of Tektite Manufacturing
Inc and is not to be used by the recipient for any
purpose other than the purpose for which it was
transmitted. The material remains the property of
Tektite and shall be returned upon request. The
material may not be reproduced or disclosed to third
parties without the written consent of Tektite.
Tolerances:
Unless otherwise
specified
X.X =
1/16"
Angular =
1.0
Drawn By:
Checked By:
Size:
File Name:
Units:
Date:
Date:
Req'd:
Description:
Tektite Manufacturing Inc.
24157 Hwy 3, Box 639, Winkler MB, R6W 4A8, Canada
CNC:
Index Service Part # File Name
Description
Qty
1 A00-0013 TEKT-0009 5MM Bushing 8
2 A00-0019 STEP-BOLT1-4X1 Step Bolt, 1/4" x 1", MB 4
3 A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD 4
4 A00-0046 TEKT-ASM-002R Side Window Hinge Right 2
5 A00-0056 TEKT-0020 Side Window Latch, L60775 1
6 A00-0058 CARRIAGE_BOLT-5-16X1 Bolt, Carriage, 5/16"x 1", YD 1
7 A00-0059 FLANGE-NUT-5-16 Flange Nut, 5/16", YD 1
8 A00-0087 TEKT-0028 Side Window Slider Bracket 2" tube 1
9 T02-0002 TOG4000-013 Side Window Glass 1
10 T02-0007 TOG4000-036R Right Side Window Weatherseal 1
Left Side Window Assembly
Daryl Furkalo
2013-04-23 Imp.
TOG4000-ASM-005-OP
B
SCALE 0.250
1
2
3
4
5
6
7
8
9
10
