Notice of Confidentiality
This material is property of Tektite Manufacturing
Inc and is not to be used by the recipient for any
purpose other than the purpose for which it was
transmitted. The material remains the property of
Tektite and shall be returned upon request. The
material may not be reproduced or disclosed to third
parties without the written consent of Tektite.
Tolerances:
Unless otherwise
specified
X.X =
1/16"
Angular =
1.0
Drawn By:
Checked By:
Size:
File Name:
Units:
Date:
Date:
Req'd:
Description:
Tektite Manufacturing Inc.
24157 Hwy 3, Box 639, Winkler MB, R6W 4A8, Canada
CNC:
Index Service Part # File Name
Description
Qty
1 TOG4000-ASM-014-AS1-SHIELD 1
2 A00-0100 FLANGE_BOLT_1-4X1-2 Flange Bolt, 1/4" x 1/2", YD 3
3 T02-0017 TOG4000-047 AS-1 Windshield 1
4 T02-0018 TOG4000-050 AS-1 Glass Seal 1
5 T02-0019 TOG4000-045 Upper Windshield Retainer 1
AS-1 Glass Assembly
Daryl Furkalo
2014-03-17 Imp.
TOG4000-ASM-015_OP
B
SCALE 0.125
2
3
4
5
To Next Page
