Notice of Confidentiality
This material is property of Tektite Manufacturing
Inc and is not to be used by the recipient for any
purpose other than the purpose for which it was
transmitted. The material remains the property of
Tektite and shall be returned upon request. The
material may not be reproduced or disclosed to third
parties without the written consent of Tektite.
Tolerances:
Unless otherwise
specified
X.X =
1/16"
Angular =
1.0
Drawn By:
Checked By:
Size:
File Name:
Units:
Date:
Date:
Req'd:
Description:
Tektite Manufacturing Inc.
24157 Hwy 3, Box 639, Winkler MB, R6W 4A8, Canada
CNC:
Index Service Part # File Name
Description
Qty
1 A00-0019 STEP-BOLT1-4X1 Step Bolt, 1/4" x 1", MB 4
2 A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD 4
3 A00-0025 BALL-LOUVER 2 1/2" Ball Louver 4
4 A00-0028 TEKT-0088 Red Dot Drier 1
5 A00-0081 KUF2880-HEADLINER-REV1 Headliner 1
6 A00-0105 R-2300-2_090902 Heater A/C Blower Unit, 2300 1
7 A00-0171 TEKT-0089 Binary Switch 1
8 A00-0173 TEKT-0090 Louver Hose 1
9 A00-0204 TEKT-ASM-011 Louver Hose Mount Plate, 2300 1
10 A00-0205 TEKT-0008_REV1 Red Dot 2300 Mount Bracket 1
A/C Compatible Additional Parts
Daryl Furkalo
2014-12-12 Imp.
TEKT-ASM-020_AC-ASM
B
SCALE 0.130
2
4
5
6
7
8
9
10
SCALE 0.130
1
3
To Next Page
