WARNING
Incorrectbatterycableroutingcoulddamage
themachineandcablescausingsparks.Sparks
cancausethebatterygassestoexplode,
resultinginpersonalinjury.
•Always
disconnect thenegative(black)
batterycablebeforedisconnectingthe
positive(red)cable.
•Always
connect thepositive(red)battery
cablebeforeconnectingthenegative(black)
cable.
4.CoatbothbatteryconnectionswithGrafo112X
(skin-over)grease,ToroPartNo.505-47,petroleum
jelly,orlightgreasetopreventcorrosion.Slidethe
rubberbootoverthepositiveterminal.
5.Installthebatterycover.
Fuses
Theretractionunitfuses(Figure59thruFigure61)are
locatedunderthehoodinthefusebox.
g011539
1
Figure59
1.Fusebox
G01 1542
1
2
2
10
20
7.5
7.5
10
7.5
7.5
10
7.5
7.5
10
Figure60
1.Fuses
Figure61
1.ReadtheOperator's
Manualforfuse
information.
7.Powerpoint—10Afuse
2.Enginepreheat—60Afuse8.Instuments—10Afuse
3.Engine,start—20Afuse9.Controlmodule—2Afuse
4.Headlights—10Afuse10.Controlmodule—2Afuse
5.Turnsignal—10Afuse11.Powerpoint—7.5Afuse
6.PowerSeat—10Afuse
