36
Important The grass deflector must be able to lower
down into position. Lift the deflector up to test that it
lowers into the full down position.
m–7868
1
6
2
4
3
8
7
5
8
1
Figure 48
1. Bolt
2. Spacer
3. Locknut
4. Spring
5. Spring installed
6. Grass Deflector
7. L end of spring, place
behind deck edge before
installing bolt
8. J hook end of spring
Cleaning and Storage
1. Disengage the blade control (PTO) lever and set the
parking brakes.
2. Remove grass clippings, dirt, and grime from the
external parts of the entire machine, especially the
engine. Clean dirt and chaff from the outside of the
engine cylinder head fins and blower housing.
Important Wash the machine with a mild detergent and
water. Do not use a pressure washer to wash the machine.
Avoid excessive use of water, especially near the control
panel and engine.
3. Check the brakes; refer to Servicing the Brakes,
page 31.
4. Service the air cleaner; refer to Servicing the Air
Cleaner, page NO TAG.
5. Grease the machine; refer to Greasing and Lubrication,
page 30.
6. Change the crankcase oil; refer to Servicing the Engine
Oil, page 28.
7. Check the tire pressure; refer to Checking the Tire
Pressure, page 30.
8. For long-term storage (more than 90 days) add a
stabilizer/conditioner additive to the fuel in the tank.
9. Empty the fuel tank using the following steps:
A. Run the engine to distribute conditioned fuel
through the fuel system (5 minutes).
B. Stop engine and wait for all moving parts to stop
before leaving the operating position.
C. Allow the engine to cool and drain the fuel tank;
refer to Servicing the Fuel Tank, page 32, or operate
engine until it stops.
D. Start the engine and run it until it stops. Repeat this
step with the throttle in the Choke position until
engine will not start.
E. Dispose of fuel properly. Recycle per local codes.
Note: Do not store stabilizer/conditioned gasoline over
90 days.
10. Remove and inspect the spark plugs; refer to Servicing
the Spark Plug, page 29.
11. With the spark plugs removed from the engine, pour
two tablespoons of engine oil into the spark plug hole,
then use the starter to crank the engine and distribute
the oil inside the cylinder.
12. Install the spark plugs. Do not connect the wires to the
spark plugs.
13. Check and tighten all bolts, nuts, and screws. Repair or
replace any part that is worn or damaged.
14. Paint all scratched or bare metal surfaces with paint
available from an Authorized Service Dealer.
15. Store the machine in a clean, dry garage or storage area,
and cover it to protect it and keep it clean.
