Toro 30530 - Wiring Diagram

37
Wiring Diagram
R
BK R
BK
BU BN BK
BROWN BLACK
OR
RED
R Y
GN
BK
BN
Y
Y GN
BU
R
GREEN BLUE
OR
MAG
YELLOW
WIRE COLOR CODES
INTERLOCK MODULE
SW4
IGN SWITCH
(SWITCH CLOSED WHEN
OPERATOR IS PRESENT)
SW3
OPERATOR PRESENCE SWITCH
SW2
NEUTRAL SWITCH
SW1
BLADE SWITCH
OR BN
C D E F B A
DELTA MODULE (2001))
(SWITCH CLOSED
WHEN IN OFF POSITION)
GND
(NEUTRAL SWITCH CLOSES
WHEN IN NEUTRAL)
(BLADE SWITCH OPENS
WHEN BLADE IS ENGAGED)
ORANGE
SPARK PLUG SPARK PLUG
IGNITION
MODULES
