Toro 30672 - Product Overview; Controls; Throttle Control; Gear Shift Lever

ProductOverview
G017539
Figure4
1.Sidedischarge
5.T-barcontrol
2.Mowerdeck6.Handle
3.Recoilstarter7.Frontcasterwheel
4.Gastank
Controls
Becomefamiliarwithallthecontrols(Figure5)beforeyou
starttheengineandoperatethemachine.
Figure5
1.Throttlecontrol7.Parkingbrake
lever-releasedposition
2.Bladecontrolbail
8.Choke
3.Powertakeofflever(PTO)
9.Ignitionswitch
4.Gearshiftlever
10.Upperhandle
5.Uppercontrolbar11.Lowerhandle
6.Lowercontrolbar
ThrottleControl
Thethrottlecontrolhastwopositions:FastandSlow.
BladeControlBail
Thebailisusedinconjunctionwiththebladecontrollever
(PTO)toengagetheclutchanddrivethemowerblades.
Releasingthebladecontrolbailwillstoptheenginewiththe
PTOengaged.
BladeControlLever(PTO)
Thisleverisusedinconjunctionwiththebladecontrolbail
toengageanddisengagethemowerdeckbeltanddrivethe
mowerblades.
GearShiftLever
Thetransmissionhasveforwardspeeds,neutralandreverse,
andhasanin-lineshiftpattern.
Important:Donotshiftwhileunitismoving,as
transmissiondamagemayoccur.
11
