Assembly
Loose Parts
Note: Use the chart below to verify all parts have been shipped.
DESCRIPTION QTY. USE
Seat
Wire Tie
Clamp
Seat Spacer
Locknut
1
1
1
4
4
Install Seat, page 10.
Front Wheel Assembly
Flat Washer
Hub Cap
Cotter Pin
2
2
2
2
Install Front Wheels, page 10.
Steering Wheel
Roll Pin
Steering Shaft Cover
1
1
1
Install Steering Wheel Assembly, page 10.
Key
2
Use in ignition and Key Choice Switches
Capscrew
Wing Nut
2
2
Secure battery cables to battery, page 11.
Hose coupling
1
Connect garden hose to washout port during
maintenance
Operator‘s Manual
1
Read manual before operating rider.
Registration Card
1
Fill out and mail to Toro.
Hang Tag
1
Read for Warranty information.
To Next Page
