Toro 71202 - Cutting Blade

Maintenance
32
Cutting Blade
To assure a superior quality of cut, keep the blade(s)
sharp. For convenient sharpening and replacement,
you may want to have an extra blade(s).
POTENTIAL HAZARD
• A blade that is worn or damaged could
break apart and pieces could be thrown at
bystanders or at you as you use the mower.
WHAT CAN HAPPEN
• Pieces of blade that may be thrown could
seriously injure or kill you or bystanders.
HOW TO AVOID THE HAZARD
• Periodically inspect the blade for wear and
damage. Immediately install a new blade if
it is worn or damaged.
Inspecting the Blade(s)
1. Remove the mower; refer to Removing the
Mower, page 34.
2. Inspect the cutting edges (Fig. 35). If the edges
are not sharp or have nicks, remove the blade(s)
and sharpen them; refer to Sharpening the
Blade(s), page 33.
3. Inspect the blade(s), especially the curved area
(Fig. 35). If you notice any damage, wear, or a
slot forming in this area (Fig. 35), immediately
install a new blade.
Figure 35
1. Cutting edge
2. Curved area
3. Wear/slot forming
151
1
2
3
Removing the Blade
1. Remove the mower; refer to Removing the
Mower, page 34.
2. Carefully tip the mower over.
3. Remove the bolt (5/8” wrench), curved washer,
retainer and blade (Fig. 36). A block of wood
may be wedged between the blade and the
mower to lock the blade when you are removing
the bolt.
4. Inspect all parts. If a defect or damage is noticed,
install new parts.
Figure 36
1. Bolt
2. Retainer
3. Blade
4. Spindle
5. Curved washer
1
2
3
4
5
