Toro 73429 - Headlights

Maintenance
32
Headlights
Removing the Bulb
1. Disengage the power take off (PTO), set the
parking brake, and turn the ignition key to
“OFF” to stop the engine. Remove the key.
2. Open the hood. Pull wire connectors off light
terminals.
3. Remove screw securing retainer bracket
(Fig. 36).
4. Lift and twist bulb out of pocket (Fig. 36).
1
2
3
4
5
m–2485
Figure 36
1. Bulb
2. Retainer
bracket
3. Tabs
4. Screw
5. Terminals
Installing the Bulb
1. Locate index boss horizontal and twist bulb
under tabs on left side of pocket (Fig. 36).
2. Hold bulb in socket with retainer bracket and
secure with screw (Fig. 36).
3. Push wire connectors onto bulb terminals
(Fig. 36).
