Maintenance
36
4. Lubricate the three grease fittings (Fig. 33).
m–4224
Figure 33
5. Replace and secure the cover.
6. Grease the fitting on the brake pedal (Fig. 34).
m–3420
Figure 34
Tire Pressure
Service Interval/Specification
Maintain the air pressure in the front and rear tires as
specified. Check the pressure at the valve stem after
every 25 operating hours or monthly, whichever
occurs first (Fig. 35). Check the tires when they are
cold to get the most accurate pressure reading.
Pressure: 20 psi (138 kPa) front and rear
m–3319
1
Figure 35
1. Valve stem
