g009195

Figure18

Note:Ifthemachineisnotproperlytracking,

refertoAdjustingtheTrackinginyourOperator's

Manual.

InstallingtheLift-Assist

Pedal

InternationalMachinesUsing

GasolineOnly

Partsneededforthisprocedure:

Carriagebolt(3/8x1-1/2inches)

Flangelocknut(3/8inch)

Procedure

1.Ifneeded,loosentheexistingboltandnutfor

thelift-assistpedal.

2.Rotatethelift-assistpedaltothecorrectposition

andinstallthecarriagebolt(3/8x1-1/2inches)

andlocknut(3/8inch)asshowninFigure19.

Tightenbothbolts.

g016346

Figure19

1.Lift-assistpedal3.Carriagebolt(3/8x1-1/2

inches)

2.Flangelocknut(3/8inch)
