Toro 74024 Setup Instructions

11
CheckingtheSeatBelt
InternationalMachinesUsing
GasolineOnly
NoPartsRequired
Procedure
Important:Ensurethebolttorqueissetbetween
67to83N∙m(49to61ft-lb).
Checktheseatbeltangleandtheseatbeltbolttorque
beforeoperating.
1.Checktheangleoftheseatbeltcomparedto
thebottomoftheseat.Theangleneedstobe
47degrees(Figure16).
2.Ifneeded,settheseatbelttothecorrectangle.
3.Checkandsetthebolttorquebetween67to83
N∙m(49to61ft-lb).
g014862
Figure16
1.Sideofseat
3.47degrees
2.Seatbeltbolt,settorque
between67to83N∙m(49
to61ft-lb).
12
Installingthe
Motion-ControlLevers
InternationalMachinesUsing
GasolineOnly
Partsneededforthisprocedure:
1Rightcontrollever
1
Leftcontrollever
4
Bolt(3/8x1inch)—2areassembled
4
Nut(3/8inch)—2areassembled
Procedure
1.Rotatethemotion-controlleverstotheupright
position.
2.Looselyinstallthecontrolleversontheinsideof
thepostsusingthe4boltsand4nuts.
Note:Installthecontrolleversinthetopand
middleholesforthehighpositionorthemiddle
andbottomholesforthelowposition.
g009040
Figure17
1.Bolt(3/8x1inch)3.Controllever
2.Handle
4.Nut(3/8inch)
3.Raisetheleversandalignthemtogetherinthe
NEUTRALpositionandtightenthebolts.
8
