8
Assembly
Loose Parts
Note: Use the chart below to verify all parts have been shipped.
DESCRIPTION QTY. USE
Wheel assembly–castor
Spacer
Washer 3/4” (19 mm)
Axle bolt 1/2-13 x 9” (230 mm)
Washer 1/2” (13 mm)
Locknut 1/2–13
1
1
2
1
2
1
Install castor wheel
Battery
Battery clamp
Battery support rod
Wing nut 1/4–20
Terminal boot
Bolt 1/4–20 x 3/4” (19 mm)
Washer 1/4”
1
1
2
4
1
2
2
Install battery
Drive Shaft
Roll Pin 3/16 x 2” (51 mm)
Bolt 3/8”–16 x 1–5/8” (41.5 MM)
Locknut 3/8”–16
1
1
2
2
Install drive shaft to mower gearbox
Pivot pin assembly
Hairpin cotter
2
2
Install mower attachment
Key
Safety Booklet
Operator’s Manual
Engine Operator’s Manual
Parts Catalog
Registration card
2
1
1
1
1
1
Read before operating machine
For ordering parts
Fill out and return to Toro
To Next Page
