Operation
18
Backward
1. Release the parking brake; refer to Setting the
Parking Brake, page 13.
2. To go backward, slowly pull the motion control
levers rearward (Fig. 9).
To go straight, move both motion control levers the
same distance (Fig. 9).
To turn move the motion control lever to neutral, on
the side you want to turn toward (Fig. 9).
To slow or stop move the motion control levers to
neutral.
Stopping the Machine
To stop the machine, move the motion control levers
to neutral, disengage the power take off (PTO), and
turn the ignition key to “OFF” to stop the engine.
Also set the parking brake when you leave the
machine; refer to Setting the Parking Brake, page 13.
Remember to remove the key from the ignition
switch.
POTENTIAL HAZARD
• Someone could move or attempt to operate
the tractor while it is unattended.
WHAT CAN HAPPEN
• Children or bystanders may be injured if
they use the tractor.
HOW TO AVOID THE HAZARD
• Always remove the ignition key and set the
parking brake when leaving the machine,
even if just for a few minutes.
Positioning the Seat
The seat can move forward and backward. Position
the seat where you have the best control of the
machine and are most comfortable.
1. To adjust, remove hairpin cotter and washer,
holding seat base down, and tip seat forward
(Fig. 10).
m–3728
2
1
3
Figure 10
1. Hairpin cotter
2. Washer
3. Seat base
2. Loosen the seat mounting bolts slide seat to the
desired position in the adjusting slots and tighten
the mounting bolts (Fig. 11).
3. Lower seat and secure with washer and hairpin
cotter (Fig. 10).
2
m–3280
1
Figure 11
1. Adjustment slot
2. Mounting bolt
