Toro 74295 - Page 48

Figure68
1.Pumprod4.Balljoint
2.Doublenuts5.Yoke
3.Locknut6.Adjustmentbolt
4.Movethemotioncontrolleverforwardandreverse,
thenbacktoneutral.Thewheelmuststopturning
orslightlycreepinreverse.
5.Openthethrottletofast.Makesurethewheel
remainsstoppedorslightlycreepsinreverse,adjust
ifnecessary.
6.Tightenthelocknutattheballjoint(
Figure68).
SettingtheLeft-handHydraulicPump
NeutralPosition
1.Loosenthelocknutsattheballjointsonthepump
controlrod(Figure69).
Figure69
1.Clevispininslot7.Spring
2.Nutagainstyoke
8.Pivotshaft
3.Adjustmentbolt9.Yoke
4.Pumprod10.Locknut
5.Doublenuts11.Balljoint
6.Jamnut
2.Starttheengine,openthrottle1/2way,andrelease
parkingbrake.RefertoStartingandStoppingthe
Enginein
Operation(page14).
Note:Themotioncontrollevermustbeinneutral
whilemakinganyadjustments.
Note:Thefrontnutonthepumprodhasleft-hand
threads.
3.Adjustthepumprodlengthbyrotatingthedouble
nutsonrod,intheappropriatedirection,untilwheel
isstillorslightlycreepsinreverse(Figure69).
4.Movethemotioncontrolleverforwardandreverse,
thenbacktoneutral.Thewheelmuststopturning
orslightlycreepinreverse.
5.Openthethrottletofast.Makesurethewheel
remainsstoppedorslightlycreepsinreverse,adjust
ifnecessary.
6.Tightenthelocknutsattheballjoints(Figure69).
WARNING
Electricalsystemwillnotperformpropersafety
shutoffwithjumperwireinstalled.
•Removejumperwirefromwireharness
connectorandplugconnectorintoseat
switchwhenadjustmentiscompleted.
•Neveroperatethisunitwithjumperinstalled
andseatswitchbypassed.
7.Afterbothpumpneutralsareset,shutoffthe
machine.
48
