Toro 74490 Setup Instructions

7
RaisingtheRollover
ProtectionSystem(ROPS)
NoPartsRequired
Procedure
1.Pullbothknobsoutandrotatethem90degrees
sothattheyarenotengaged(Figure3).
2.Raisetherollbartotheoperatingpositionand
rotatetheknobsuntiltheymovepartiallyinto
thegrooves(Figure3).
g035064
Figure3
1.Rollbarintheuprightposition
2.ROPSknobinthelatchedposition
3.PulltheROPSknobout.
4.RotatetheROPSknob90degrees.
5.ROPSknobintheunlatchedposition
3.Raisetherollbartothefulluprightpositionwhile
pushingontheupperrollbarsothatthepins
snapintopositionwhentheholesalignwiththe
pins.
4.Pushontherollbarandensurethatbothpins
areengaged(Figure3).
