Toro 74490 Setup Instructions

8
CheckingtheGrass
Deector
NoPartsRequired
Procedure
Ifthereareplastictiesholdingthegrassdeectorup,
removethemandlowerthedeectorintoplace.
WARNING
Anuncovereddischargeopeningcouldallow
themachinetothrowobjectstowardyouor
bystanders,resultinginseriousinjuryor
death.Also,contactwiththebladecould
occur.
Neveroperatethemachinewithoutacover
plate,amulchplate,grassdeector,orbagger
installed.
1.Makesurethat1endofthespringisinstalled
behindthedeckedgebeforeinstallingthebolt
asshowninFigure4.
2.Placetheotherendofthespringaroundgrass
deector(Figure4).
Important:Thegrassdeectormustbefree
torotatewithdownwardtension.Liftthe
deectoruptothefullopenpositionand
ensurethatitrotatesfreely,withoutbinding
intothefulldownposition.
g021181
Figure4
1.Grassdeector3.Endofspring
2.Spring
4.Deckedge
5
