23
Where to Add Grease
Figure 23
Lubrication List
Item Name Quantity Interval (hours) Lubricant
1 Front wheel—grease fitting 2 25 Grease
2 Steering ball joints 4 50 Oil
3 Steering sector gear 1 50 Grease
4 Steering pinion gear 1 25 Grease
5 Steering shaft bearing 1 50 Oil
6 Steering shaft bearing 1 50 Oil
7 Motion lever—grease fitting 1 50 Grease
8 Shaft hub for lifting the mower deck 1 50 Oil
9 Motion link ball joints 4 50 Oil
10 Brake pedal hub 2 50 Oil
11 Parking brake ring 1 50 Oil
12 Steering bearing 1 25 Grease
13 Left and Right Spindle—grease fitting 2 25 Grease
14 Mower deck hinged pin 6 When removed Grease
15 Front axle pivot pin 2 When removed Grease
16 Front axle pivot pin 2 25 Grease
