Toro 74582 - Product Overview; Controls

116-1716
1.Fuel6.Hourmeter
2.Empty
7.PTO
3.Half
8.Parkingbrake
4.Full9.Neutral
5.Battery
10.Operatorpresenceswitch
ProductOverview
Controls
Becomefamiliarwiththecontrols(Figure4)beforeyou
starttheengineandoperatethemachine.
Figure4
1.Ignition/lightswitch
6.Hoodopening
2.Throttlecontrol/Choke
lever
7.Forwardspeedpedal
3.Brakepedal8.Reversespeedpedal
4.Parkingbrakelever9.Bag-on-demandpedal
5.Bladecontrol(PTO)knob
10
