Toro 74650 - Stopping the Machine; Adjusting the Height of Cut; Adjusting the Anti-Scalp Rollers

StoppingtheMachine
Tostopthemachine,movethemotion-controlleversto
NEUTRALandoutwardtothePARKposition,disengagethe
blade-controlswitch,ensurethatthethrottleisintheFAST
position,andturntheignitionkeytoOFF.Removethekey
fromtheignitionswitch.
WARNING
Childrenorbystandersmaybeinjuredifthey
moveorattempttooperatethemowerwhileitis
unattended.
Alwaysremovetheignitionkeyandmovethe
motion-controlleversoutwardtothePARKposition
whenleavingthemachineunattended,evenifjust
forafewminutes.
AdjustingtheHeightofCut
Note:Thetransportpositionisthehighestheight-of-cut
positionorcuttingheightat115mm(4-1/2inches)asshown
inFigure26.
Heightofcutiscontrolledbytheleverlocatedtotherightof
theoperatingposition(Figure26).
g027697
Figure26
AdjustingtheAnti-Scalp
Rollers
ForMachineswith107cm(42-inch)
MowerDecks
Wheneveryouchangetheheightofcut,adjusttheheight
oftheanti-scalprollers.
Note:Adjusttheanti-scalprollerssotherollersdonottouch
thegroundinnormal,atmowingareas.
1.Parkthemachineonalevelsurfaceanddisengagethe
blade-controlswitch.
2.Movethemotion-controlleversoutwardtoPARK
position,shutofftheengine,removethekey,and
waitforallmovingpartstostopbeforeleavingthe
operatingposition.
3.Adjusttheanti-scalprollersto1ofthefollowing
positions:
•Upperhole—usethispositionwiththemower
deckinthe63mm(2-1/2inch)andbelowthe
height-of-cutpositions(Figure27).
•Lowerhole—usethispositionwiththemowerdeck
inthe76mm(3inch)andabovetheheight-of-cut
positions(Figure27).
g019929
1
2
3
4
5
g019929
Figure27
1.Anti-scalproller4.Upperhole—themower
deckinthe63mm(2-1/2
inch)andbelowthe
height-of-cutpositions
2.Lowerhole—themower
deckinthe76mm(3
inch)andabovethe
height-of-cutpositions
5.Bolt
3.Flangenut
