Toro 76601 - Product Overview; Controls

ProductOverview
g368672
Figure4
1.Height-of-cutdeck-lift
pedal
7.Worklights(standardon
Model76602;optionalkit
onModel76601)
2.Height-of-cutpositions
8.Fuelcap
3.Transportlock9.Parking-brakelever
4.Controls
10.Mowerdeck
5.Motion-controllevers
11.Casterwheel
6.Rollbar
Controls
Becomefamiliarwithallthecontrolsbeforeyoustart
theengineandoperatethemachine.
ControlPanel
g368671
Figure5
1.Keyswitch
5.Chokecontrol
2.Blade-controlswitch
(powertakeoff)
6.Lightswitch(standardon
Model76602;optionalkit
onModel76601)
3.Hourmeter
7.Positionforoptionalpower
point
4.Throttlecontrol
KeySwitch
Thekeyswitch,usedtostartandshutofftheengine,
has3positions:OFF,RUN,andSTART.Referto
StartingtheEngine(page22).
ChokeControl
Usethechokecontroltostartacoldengine.
ThrottleControl
Thethrottlecontrolstheenginespeed,andithasa
continuous-variablesettingfromtheSLOWtoFAST
position(Figure5).
Blade-ControlSwitch(Power
Takeoff)
Theblade-controlswitch,representedbya
power-takeoff(PTO)symbol,engagesand
disengagespowertothemowerblades(Figure5).
11
