Toro 76601 - Controls System Maintenance; Adjusting the Control-Handle Position

g036859
Figure57
1.Idlerpulley4.Pump-drivebelt
2.Idler-springpost5.Righthydraulic-pump
pulley
3.Enginepulley
6.Lefthydraulic-pumppulley
9.Installtheclutchstop(Figure56).
10.Installthemowerbelt;refertoBeltMaintenance
(page45).
ControlsSystem
Maintenance
Adjustingthe
Control-HandlePosition
Iftheendsofthelevershitagainsteachother,referto
AdjustingtheMotion-ControlLinkage(page48).
AdjustingtheHeight
Youcanadjustthemotioncontrollevershigheror
lowerformaximumcomfort.
1.Parkthemachineonalevelsurface,disengage
theblade-controlswitch(PTO),andengagethe
parkingbrake.
2.Shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Removethehardwareholdingthecontrollever
tothecontrol-armshaft.
g035858
Figure58
1.Bolts
3.Controllever
2.Slottedhole4.Control-armshaft
4.Movethecontrollevertothenextsetofholes.
Securetheleverwiththehardware.
5.Repeattheadjustmentfortheoppositecontrol
lever.
47
