Choke Control
Use the choke control to aid in starting a cold engine.
G419508
Engaged
Disengaged
Motion-Control Levers
Use the motion-control levers to drive the machine forward, reverse, and turn either
direction.
Park Position
G438246
Move the motion-control levers outward from the
center to the P
ARK position to engage the parking
brake when stopping or exiting the machine.
Height-of-Cut Pin
The height-of-cut pin works with the foot pedal to lock the deck in a specific cutting height.
Adjust the height of cut only when the machine is not moving.
Deck-Lift Pedal
Use the deck-lift pedal to briefly raise the mower deck from the seated position to avoid
obstacles or when adjusting the height of cut.
Product Overview: Control Panel Page 3–3 3465-589 C
