Toro 79392 - Installing the Blowout Baffle; Installing the Chute

7
InstallingtheBlowout
Bafe
NoPartsRequired
Procedure
Note:Thisprocedureisonlyformachineswith
54-inchmowerdecks.
Securetheblowoutbafetothemowerdeckusing2
carriageboltsand2locknuts(Figure20).
g028409
Figure20
1.Locknuts3.Bolts
2.Blowoutbafe
8
InstallingtheChute
Partsneededforthisprocedure:
1
Chute
Procedure
1.Anglethemetaltabatthefrontofthechuteinto
theslotinthebracketweldedtothemowerdeck
(Figure21).
g015203
Figure21
1.Chute
3.Bracket
2.Metaltab
2.Pivotthechutebackandtowardthedecksothat
thechuteisushwiththemowerdeck(Figure
22).
