g030900
Figure7
1.Bolt
3.Reinforcementplate
2.Rollbar4.Flangenut
RemovingtheRollBar
Important:Useanassistanttosupporttheroll
barwhenyouremovetheboltssecuringittothe
machine.
1.Removetheboltssecuringtherollbartotheleft
sideofthemachine(Figure8).
g030675
Figure8
1.Bolts2.Rollbar
2.Useanassistanttohelpyouremovetherollbar
fromthemachine.
3.Storetherollbar.
